-1+2 (3 Floors) Pit Design Puzzle Parking System

-1+2 (3 Floors) Pit Design Puzzle Parking System

China -1+2 (3 Floors) Pit Design Puzzle Parking System supplier

Large Image :  -1+2 (3 Floors) Pit Design Puzzle Parking System

Product Details:

Place of Origin: Qingdao, China
Brand Name: STMY
Certification: ISO & CE
Model Number: PSH-1+1, PSH-1+2, PSH-2+2

Payment & Shipping Terms:

Minimum Order Quantity: 1 Unit
Price: $2000-2500/per car space
Packaging Details: Standard Export Package
Delivery Time: 30 days
Payment Terms: 30%TT in advance, 70%TT before shipping
Supply Ability: 1000sets/month
Detailed Product Description
Type: Carport

Product Specifications:

Brand Name  STMY
Model No.  QDMY-PSH(-1+1);  QDMY-PSH(-1+2); QDMY-PSH(-2+2);

 2,3,4 Floors Pit Design Automated Puzzle Parking System

Mode of Operation                  IC card/Manual buttons/Remote controller

Car Weight


Car Size(mm)

(Length x Width x Height)



Mode of Drive

 Motor & Chain (Standard design) /Hydraulic

Lifting Motor Speed


Sliding Motor Speed  7.35m/min
HS Code  842890200

Power Supply

 380V/50Hz  3 Phase 5 Wires

 (Cutomized according to different country's demand)

Warning Device  Yes
Safeguard Device  Fixed anti-falling hook devices
Lift Motor Power


Slide Motor Power      0.2KW
Outer Size   Please see below dimensions
Surface Treatment     Spray panit or Hot dipped galvanized  (Optional)

 Blue, Grey, Yellow, Red,  (Customized )


 ISO and CE

Warranty Time  5 years for structure,  12 months for electrical key parts


Actuating Device (Optional):

1. Motor + Chain + Car Loading Pallet

2. Motor + Steel Rope + Car Loading Pallet

3. Hydraulic


Working Principle:

The equipment is designed as 2, 3 or 4 levels automatic puzzle parking system, one or two levels are above ground, and one or two levels are underground in a pit. There is an empty space on the upper level for exchange. The spaces of down level can shift up and down automatically, and the spaces of the upper levels can slide horizontally automatically. When the pallets run to the ground level, then cars can be parked or driven out.



Take full use of land to raise more parking spaces;

Reliable motor with chain or steel rope drives;

High speed and fast pick cars;

A whole system for safety protection for cars or personals;

Saving energy and environmental protection;

Advanced PLC microcontroller programmed and has Liquid crystal display;

Very simple operated with a smart card or manual buttons;

Fashionable and elegant appearance will can be easily in harmony with surrounding environmen


Protection Device

Safety anti-falling hook;

Over or under voltage protection;

Wrong or lack phase protection;

Motor overload safety protection;

Overtime/short time safety protection;

Vehicle positioning device;

Vehicle length detection and entrance photoelectric safety device;

Warning light when operation;

Emergency stop device;

Power-off brake;

Fault diagnosis display on liquid;

The limit switch status tracking detection.


Adapted Places

Residential parking lot, apartment, public parking place, hotels, schools, shopping mall, commercial center and office buildings, etc...



-1+2 (3 Floors) Pit Design Puzzle Parking System


-1+2 (3 Floors) Pit Design Puzzle Parking System


-1+2 (3 Floors) Pit Design Puzzle Parking System


-1+2 (3 Floors) Pit Design Puzzle Parking System


 -1+2 (3 Floors) Pit Design Puzzle Parking System


-1+2 (3 Floors) Pit Design Puzzle Parking System


-1+2 (3 Floors) Pit Design Puzzle Parking System


-1+2 (3 Floors) Pit Design Puzzle Parking System

-1+2 (3 Floors) Pit Design Puzzle Parking System

-1+2 (3 Floors) Pit Design Puzzle Parking System

Note: The width can be increased according to your land size, please provide us your land size, we can make design for you.
