Product Specifications:
Brand Name | STMY |
Model No. |
QDMY-SJG 1 level above ground, 1 level underground in a pit |
Type | Pit design scissor parking lift for 2 cars |
Mode of Operations | Manual buttons/Keys |
Car Capacity |
≤2000kgs; 3000kg; 3500kg (Customized) |
Mode of drive |
Hydraulic |
Car Size (L×W×H) |
5000mm×1850mm×1550mm; 5000mm×1850mm×2050mm; (Customized) |
Platform Size (LxW) |
5500mm x 2800mm (Customized) |
Lifting Height |
2200mm (Customized) |
Safeguard device | Whole protection and anti-falling hook device |
Lifting Speed | 4-6m/min |
Stop at any height | Yes, can be set |
Work Noise | < 60dB ( A ) |
Electricity |
110v 220V/240V/380V (customized for different country) |
Motor Power | 5.5-7.5KW |
Maximum Working Pressure | 16 MPa |
HS Code | 84289020 |
Surface Treatment |
High-grade anti-corrosion paint |
Color |
Red, Blue, Grey, Yellow etc. (customized according to user demand ) |
Certification | ISO9001 and CE |
Actuating Device:
Hydraulic Pump + Cylinder + Steel Rope + Car Loading Platform
Working Principle:
This pit design scissor parking lift is designed for 2 cars. Usually, the bottom level car is underground in a pit, the upper level car is above ground. The two car spaces are united as a whole unit and lifted up and down together, when the car platform is lifted to the ground level,
the user can pick or park his car easily.
Characteristics:
Online Video Show:
http://youtu.be/vTbBz_gM3pI
Pictures:
Sample Drawings:
Remark: The lifting table size, car weight, lifting height can be customized according to customers' request.
