2. Two Post Tilt Parking Lift QDMY-606

2. Two Post Tilt Parking Lift QDMY-606

China 2. Two Post Tilt Parking Lift QDMY-606 supplier

Large Image :  2. Two Post Tilt Parking Lift QDMY-606

Product Details:

Place of Origin: Qingdao, China
Brand Name: STMY
Certification: ISO90001 & CE
Model Number: QDMY-606

Payment & Shipping Terms:

Minimum Order Quantity: 1-3 Sets
Price: $1800-1900/Per set
Packaging Details: Standard Export Package
Delivery Time: 20-30 days
Payment Terms: 30%TT in advance, 70%TT before shipping
Supply Ability: 3000 sets/month
Contact Now
Detailed Product Description

Product Specifications:

Brand Name STMY
Model No. QDMY-606
Type Two post tilting parking lift
Mode of Operation Manual control buttons / Keys
Car Weight ≤2700kg
Car Size (L/W/H) ≤5000mm×1850mm×1550mm
Lifting Height 1600-1850mm
Mode of Drive Hydraulic
Rise/Fall Time 45s / 40s
Motor Power 2.2KW
Working Voltage                              110V-415V, 1 or 3 Phases
Warning Device Yes
Safeguard Device Fixed anti-falling lock device
Control System Voltage AC24
Car Platform Thickness 2.0mm
Outer Size Please see below dimensions
Machine Weight 1100kg
Surface Treatment

Galvanized treatment and high-grade anti-corrosion paint

Color

Red, Blue, Grey, Yellow etc.

( customized )

Certification ISO90001 and CE



Actuating Device:

Hydraulic Pump + Cylinder + Steel Rope + Car Loading Pallet



Working Principle:

This parking system is designed 2 spaces of up and down as one unit. The bottom car can go in and out directly. When the upper space needs to park a car, the car in the bottom should be driven out.



Characteristics:

  • Simple operation
  • Safe and reliable
  • Convenient in and out of car
  • Ultra low noise
  • Small space occupation
  • Beautiful and fashionable in appearance
  • Easy and fast installation
  • Both suitable for home use and public use

Adapted places:

Underground basement, Apartment, Public Parking place, shopping mall, etc.



Online Video Show:

https://youtu.be/4VA67AwriFU



Pictures:

2. Two Post Tilt Parking Lift QDMY-606

2. Two Post Tilt Parking Lift QDMY-606

2. Two Post Tilt Parking Lift QDMY-606

2. Two Post Tilt Parking Lift QDMY-606

2. Two Post Tilt Parking Lift QDMY-606

2. Two Post Tilt Parking Lift QDMY-606

2. Two Post Tilt Parking Lift QDMY-606

2. Two Post Tilt Parking Lift QDMY-606

Structure and Dimensions:



2. Two Post Tilt Parking Lift QDMY-606

FAQ

1. What trade term you can accept?
----FOB, CFR, CIF, EXW, FCA. (If you want check the shipping cost, tell us your nearest sea port).

2. What payment term can you accept?
----100%TT in advance for sample order (1-3 sets)

----30%TT in advance, and 70%TT before shipping or 70%LC at sight for full container order.

3. How about the loading information and HS Code?

---The HS code is 84289020

---8 sets/20’GP container; 16 sets/40’GP container (Individually packaged )

---16 sets/20’GP container; 22 sets/40’GP container (Every two packaged)


4. How about the lead time?
---20-30 days (In peak season, 45 days).

5. Can you provide OEM service?
--Yes, we can provide OEM service according to the requirement of the client;

6. Can you make design for our land?
--Yes, send me your land layout, our engineer can make design and provide the best parking solution to you and your clients;

7. Do you provide training services:
--Yes, we provide free trainning services in our factory, to teach your engineer about how to install and rountine mantenace knowledge;

8. How about the installation?
----This model of product is simple structure, usually we send installation manual to the client, and they can install it themselves.

9. What is warranty term?

---12 months for electrical parts, 5 years for mechanical structure.



10. What are the certificates?

---ISO90001 & CE.



11. Why it is a tilting structure design?

---This parking lift is suitable for low ceiling garages, with minimum height require ≥3000mm.



12. Does it have photoelectric sensor?

---No, it doesn't.



13. Can the posts  be shared with each other?

---No, cannot share.
